Elbow Joint External Fixator
- Complete set for external fixation of elbow joint
- Includes 1 Elbow Joint 5mm, 4 Rod-Pin Couplings (3/4mm Pin, 5mm Rod), and 4 Apex Pin Self-drilling 4*120mm
- Designed for stable fixation and support of the elbow joint
- High-quality materials for durability and reliability
- Ideal for orthopedic surgery and post-traumatic rehabilitation
- SKU
- OD-00015
- Brand
- Orthopedic Drills
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
Elbow Joint External Fixator
Complete external fixation system for stable elbow joint support and post-traumatic rehabilitation. Engineered with precision-machined components and self-drilling pins for reliable intraoperative performance and patient outcomes.
Clinical overview
The Elbow Joint External Fixator is a comprehensive system designed for stable external fixation of complex elbow joint injuries. This modular configuration provides surgeons with the flexibility to adapt fixation geometry to patient anatomy while maintaining rigid construct stability. The system combines a precision-engineered elbow joint articulation with self-drilling pins and rod-pin couplings to create a reproducible, biomechanically sound fixation framework suitable for acute trauma, staged reconstruction, and post-traumatic rehabilitation protocols.
The self-drilling pin design eliminates the need for separate drilling steps, reducing operative time and improving intraoperative workflow efficiency. High-quality stainless steel construction ensures durability through the entire treatment course, while the modular coupling system allows for easy adjustment and reconfiguration as clinical requirements evolve during the healing phase.
Key features & surgeon benefits
Complete Fixation System
- Dedicated elbow joint articulation for anatomic alignment
- Four rod-pin couplings for multi-directional fixation
- Four self-drilling pins (4×120mm) for secure bone purchase
Streamlined Operative Technique
- Self-drilling pins eliminate separate drilling steps
- Modular coupling design enables rapid assembly and adjustment
- Intuitive component interface reduces operative time
Cost-Effective Solution
- Complete kit reduces need for additional component purchases
- Durable stainless steel construction minimizes replacement costs
- Reusable components support sustainable surgical practice
Adaptable Design
- Modular rod-pin couplings accommodate variable pin and rod sizes
- Elbow joint articulation supports multiple fixation angles
- Available for OEM integration and custom configurations
Technical specifications
| Indications | Elbow joint fractures, post-traumatic stabilization, complex fracture management, staged reconstruction |
|---|---|
| Sizes / range | 5mm rod diameter; 3/4mm pin compatibility; 4mm self-drilling pins (120mm length) |
| Material | Stainless Steel (surgical grade) |
| Sterilisation | Steam sterilizable (autoclavable) |
| Packaging | Complete kit in sterile or non-sterile configuration |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item Code | Description | Qty |
|---|---|---|
| 7100-0701 | Elbow Joint 5mm | 1 |
| 7100-0702 | Rod-Pin Coupling (3/4mm Pin, 5mm Rod) | 4 |
| 7100-0703 | Apex Pin Self-drilling 4×120mm | 4 |
Get in touch for pricing & availability
Contact our sales team to discuss pricing, delivery timelines, and custom configuration options for your facility or OEM partnership requirements.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
